Earthing straps
Product information
Before concreting the bottom plate, a so called earthing strap is laid in the ground. With the earthing strap the building is earthed. The galvanised earthing strap is connected with the distribution box by the electrician via a separate line.
Technical data
MEISER provides the following dimension:
| Dimensions | Coil weight | Zinc coating | |
| kg | Metre | ||
| 30 x 3,0 | 50 | 70 | Z300/Z500 |
| 30 x 3,5 | 25 | 30 | Z300/Z500 |
| 30 x 3,5 | 50 | 60 | Z300/Z500 |
| 30 x 4,0 | 50 | 52 | Z300/Z500 |
| 40 x 4,0 | 50 | 39 | Z300/Z500 |
| 40 x 5,0 | 50 | 32 | Z300/Z500 |
Other dimensions on request.
